Eetamax NORA Flood light is a perfect lighting solution for outdoor illumination. Eetamax LED Flood lights are extremely reliable, robust, durable, and with low maintenance while at the same time delivering uniform, glare-free light distribution. Made out of aluminum pressure die cast housing with toughened glass cover & special gasket to achieve high ingress protection for weatherproof outdoor use. They come with all necessary protections to ensure maintenance free operation at large installation heights. Available in wide beam angle light spread for open area lighting, and in asymmetric and narrow beams necessary for sports lighting and other critical application
Features
- Aesthetically elegant & Robust design
- Excellent thermal design for long life
- Delivers Uniform Light distribution
- 10kV Surge Protection and inbuilt Electronic Protections
Applications
- Sports Stadiums
- Railway Yards
- Toll Booths, High Masts
- Shipyards & Dockyards
- Storage Yards
- Airport Terminals
- Industrial Outdoor Areas, Open Spaces
Save CAPEX
Save OPEX
IP66
IK08
LM80
>140 lm/W
| Mechanical Specification | |
Fixture Housing |
Pressure die cast aluminium housing for effective thermal management with protective toughened glass cover. |
Diffuser Closure |
Toughened Glass |
IP & IK |
IP66 & IK08 |
| Luminaire Specification | |
| Wattage | 30W / 40W / 50W / 60W / 80W / 100W / 120W / 150W / 200W / 240W / 300W / 350W / 400W |
| L70 Life | >70,000 Br. hrs |
Operating Temperature |
From -20° to +50° C |
| LED lamp | |
Light Source |
SMD |
Lamp Efficacy |
>190 lm/W |
Colour Temperature |
6500K (Other CCT Available on request) |
| CRI | >70 |
| Certification / Report |
LM79, LM80, Photo Biologically Safe |
| Beam Angle |
Symmetric 30° / 60° / 90° / 120° & Asymmetric T2 type lens |
| LED Driver Specification | |
Type of Driver |
Constant Current |
Input Voltage Range |
30W to 100W (150VAC ~ 265VAC) 120W to 400W (100VAC ~ 305VAC) |
Frequency Range |
50 Hz - 60 Hz |
| Power factor | > 0.97 |
| Total Harmonic Distortion | < 10 % |
| Surge Protection | 6 kV + 10 kV External SPD |
| Protection | Surge Protection Output Short Circuit Overload Protection Over Voltage Protection Thermal Protection Mis- Wiring Protection 440 VAC protection |
| Optics | |
| Optics Type | Rotationally symmetric or asymmetric light spread lens |
| MOC of Optics | PC/ PMMA |
EETAMAX NORA FLOOD LIGHT STANDARD PARAMETERS
| Sr. | System Wattage | Lumen Package | System Efficacy (Lm/W) | Length (mm) | Width (mm) | Height (mm) | Weight (Kg) |
| 1 | 30W | 4050 lm | 135 lm/W | 255 mm | 183 mm | 160 mm | 2.5 Kg |
| 2 | 40W | 5400 lm | 135 lm/W | ||||
| 3 | 50W | 6750 lm | 135 lm/W | ||||
| 4 | 60W | 8100 lm | 135 lm/W | ||||
| 5 | 80W | 11200 lm | 140 lm/W | 380 mm | 300 mm | 240 mm | 6.6 Kg |
| 6 | 100W | 14000 lm | 140 lm/W | ||||
| 7 | 120W | 16800 lm | 140 lm/W | ||||
| 8 | 150W | 21000 lm | 140 lm/W | ||||
| 9 | 200W | 28000 lm | 140 lm/W | 430 mm | 330 mm | 270 mm | 9 Kg |
| 10 | 240W | 33600 lm | 140 lm/W | ||||
| 11 | 300W | 42000 lm | 140 lm/W | 520 mm | 330 mm | 220 mm | 10.5 Kg |
| 12 | 350W | 49000 lm | 140 lm/W | ||||
| 13 | 400W | 56000 lm | 140 lm/W |
